Belt drier


Name:	Belt drier
Introduction:	DWC series multi-layer band type drying machine is widely applied in food, subsidiary agricultural products, dehydrated vegetables, traditional chinese medicinal materials, feed and chemical industry for drying of plate, stripe and particle material. It has features of high-efficiency, energy saving, paragraphing drying, even heat exchange.

Brief introduction:

DWC series multi-layer band type drying machine is widely applied in food, subsidiary agricultural products, dehydrated vegetables, traditional chinese medicinal materials, feed and chemical industry for drying of plate, stripe and particle material.

It has features of high-efficiency, energy saving, paragraphing drying, even heat exchange.

Technical parameters:

Item\Model	GWC-20	GWC-25	GWC-32 4m	GWC-36 4.5m	GWC-48 6m	GWC-60 7.5m	GWC-80 10m
area of material m²	20	25	32	36	48	60	80
steam working pressure Mpa	0.4-0.7
gas consumption kg/h	150-300	180-375	240-480	270-540	360-720	450-900	600-1200
drying period min	20～200	60～600	100～1000
evaporative power kg·H₂O/h	100-200	125-250	160-320	180-360	300-480	300-600	400-800
installed capacity Kw	5.5	5.5	5.5	5.5	14.2	15.2	15.2
total capacity t	8	8	8.5	10	11	13	15
boundary dimension dim.mm	8875 ×2408 ×3385	9875 ×2408 ×3385	11475 ×2408 ×3385	11475 ×2408 ×3385	14675 ×2408 ×3385	14675 ×2840 ×3385	15675 ×2840 ×3385
